R-78HB24-0.3L, Recom Switching Regulator, Through Hole, 24V dc Output Voltage, 36 → 72V dc Input Voltage, 300mA Output Current,, Импульсные стабилизаторы

R-78HBxx-0.5L Series

Non-isolated
Medical safety approval EN-60601-1-2
High efficiency switching regulator
High voltage input range, up to 72V
Thermal shutdown and continuous short circuit protection
Low ripple and noise
Low profile
Pin-out compatible with LM78XX Linear regulators
”L” version with 90° pins

Note

De-rate above 71°C operating temperature.
MTBF to MIL_HDBK 217F.

Standards

EN-55022, EN-55024, EN-60601-1-2, EN-60950-1

RECOM Switching Regulator, 36 to 72V DC Input Voltage, 24V DC Output Voltage - R-78HB Series - R-78HB24-0.3L

Use this switching regulator from RECOM to convert incoming power into a voltage suitable for your attached device. It's capable of converting a high input voltage up to 72V DC into a steady 24V DC output, making it a reliable choice. It's easy to install this switching regulator thanks to its through-hole method and as it weighs just 4g, it won't put undue stress on your setup

Features & Benefits

• SIP package type reduces surface area and dimensions of 11.5 (L) x 8.5 (W) x 17.5mm (D) make it a practical choice for installation in small spaces
• Operating efficiency of 92% for minimal energy wastage
• Line regulation of ±1% ensures reliable output voltage
• Load regulation of ±0.6% gives dependable power despite load changes
• Broad operating temperature range from -40°C to +85°C for use in harsh industrial environments

Applications

• Industrial power supplies
• Factory automation
• Medical equipment

Why are switching regulators needed?

Switching regulators are used to change input direct current voltage to the current voltage needed to run your component without damage.
