RO-0505S/P, Recom RO DC-DC Converter, 5V dc/ 200mA Output, 4.5 → 5.5 V dc Input, 1W, Through Hole, +85°C Max Temp -40°C Min, Преобразователь

Recom 1W SIP Single Output Unregulated Isolated DC-DC Converter - RO Series

Unregulated outputs
1kVdc isolation
Efficiency at full load up to 85%
Short circuit protection
Fully encapsulated UL94V-0 package
SIP4 industry standard pinout

Note

MTBF to MIL-HDBK 217F
Operating temperature is without derating.

Standards

EN-60950-1

RECOM DC-DC Converter, Single Output, 80% Efficiency - RO Series - RO-0505S/P

When you need to maintain your power supply at a steady 5V, give the job to this DC-DC converter from RECOM. It regulates an input voltage of between 4.5 and 5.5V, so you can be sure of a stable output even if the supply's wobbly. As it's fully encapsulated, this tough device shrugs off contaminants and abrasion with ease. Plus, with a wide operating temperature range between -40°C and +85°C, challenging industrial environments won't throw it off its game. The simple through-hole mounting method creates robust, vibration-resistant connections, making this a solid choice for heavy-duty tasks.

• Standardised SIP-4 package is widely compatible for easy integration into your system
• Flame-retardant housing self-extinguishes in less than 10 seconds to help prevent the spread of fire
• 80% efficiency rating makes this a sustainable option that runs cool

Applications

• Telecommunications equipment
• Medical technology
• Consumer electronics

How long will this converter last?

Thanks to an impressive 985,000-hour mean time between failures, you can rely on this resilient component to keep performing at its best over the long term.
