X80-04-02, Moflash X 80 Red Xenon Beacon, 115 → 230 V ac, Flashing, Surface Mount, Маячок

Moflash Beacon

The Moflash red lens xenon beacon is suitable for a wide range of local signalling applications where an affordable and energy-efficient solution is required. It is controlled via a PCB and puts out a very brief but bright flash of white light by ionizing and then discharging a large current through the xenon gas.

Note:
The X80 series products are supplied as sealed units. Replacement lamps are not available.

Features and Benefits

The supply voltage is 115VAC/230VAC
Flashy bright 2.0J xenon signal
Low current consumption(100mA/50mA)
Can be wall or surface mount
Continuously rated
Wide operating voltage
120° prime light output from vertical axis
Dustproof and submersible in water
Height is 50mm and base diameter is 76mm
Operating voltage ranging between -20°C and 55°C

Applications

Refuge trucks
Utility vehicles
Agriculture
Plant and contracting,
Fleet vehicles
Industrial
Commercial buildings

Certifications

IP67 rated
CE certified
