22-01-3127, Molex, 2695 Female Connector Housing, 2.54mm Pitch, 12 Way, 1 Row, Корпус разъема

Molex KK Range of 2695 Series Housings

This range of Series 2695 Connector Housings feature a 2.54 mm pitch and form part of the KK Interconnect system from Molex, which provide a simple and economical way to make multipole connections to printed circuit boards. When fitting the terminals into the housings it is essential that the Molex insertion tool is used for the correct fitting of these terminals. Please see engineering note for more details.

Features and Benefits

• 2.54 mm pitch
• Wire to board connections and fittings
• Natural (white) colour
• Single Row
• Housings 22-01-2xxx have friction lock ramps
• Housings 22-01-3xxx have friction lock ramps and polarizing ribs

Molex Connector Housing, Lock To Mating Method, 0°C Minimum Operating Temperature - KK 254 Series - 22-01-3127

Got a complex PCB system on your hands? Call on this connector housing from Molex to simplify things. It has 12 contacts, so you can make multiple cable connections with a single unit. Compact dimensions of 31.04 (L) x 4.82 (H) x 12.7mm (D) mean it fits neatly into a busy circuit board. As this device is made from sturdy nylon, it's resistant to impact and abrasion, so you can be sure of reliable performance in tough conditions.

Features & Benefits

• Handles harsh temperatures up to +75°C without losing form
• 250V maximum voltage rating suits low-power applications
• 2.54mm pitch for wide compatibility with commonly used conductors

Applications

• Automotive industry
• Production lines
• Consumer power supplies

How much does this component weigh?

It weighs in at just 1.28g, so it doesn't put unnecessary load on your board.
