EA Elektro-Automatik Switching Power Supply, EA-PS 824-80 Single, 24V dc, 4A, 96W, 1 Output, 90 → 264V ac Input, Источник питания

EA Elektro-Automatik Embedded Switch Mode Power Supply

The EA Elektro-Automatik EA-PS 800 Series 96W single output AC to DC embedded switch mode power supply has an output current of 4A at 24VDC. The 19in plug-in power supply has a European format. The active PFC has a true wide-input range, fully independent adjustment and natural cooling suitable for ambient temperatures of up to 70°C. Hence, it is ideal for situations requiring reliability and high performance. It has a universal input supply voltage rating ranging from 90VAC to 264VAC.

Features and Benefits

Output voltage adjustable by trimmer
Up to 92% efficiency by combining fly-back converter and synchronous rectifier principle
No minimum load required
No cross regulation effects
Remote sense
Overvoltage protection
Over temperature protection
Inhibit
Front panel LEDs
Remote ON/OFF and power fail signal
Electrical connection via H15 male connector
Rack mount
Enclosed package type

Applications

Control, test and measurement
Telecommunication
Data communication applications

Certifications

EN60950
EN55022
UL approved
TUV approved
DIN 41494 compliant
