6715 GY005, Alpha Wire EcoWire Series Green/Yellow 0.75 mm² Hook Up Wire, 18 AWG, 16/0.25 mm, 30m, MPPE Insulation

Alpha Wire 600 V, mPPE Hook Up Wire, EcoWire Series

EcoWire from Alpha Wire is the latest innovation in hook-up wire. EcoWire combines increased performance with a minimal environmental impact due to it being fully recyclable.
This hook up wire is manufactured from a modified polyphenylene ether (mPPE) thermoplastic. EcoWire can be easily recycled since it does not contain hazardous materials. The enhanced dielectric properties of this hook up wire make it possible to have a reduced wall thickness while still maintaining the same electrical properties as PVC.

Features and Benefits

• Fully recyclable
• Up to 45% smaller diameter than PVC
• Up to 40% lighter than other insulation materials
• Excellent dielectric strength
• Low specific gravity
• Flame retardant to UL VW-1 rating
• EcoWire Plus range available with excellent resistance to hazardous oils and chemicals
• Stranded or solid tinned copper conductors
• Available in lengths of 100 ft (30.5 m) and 1000 ft (305 m)

What is UL/CSA standard?

The UL standard (Underwriters Laboratories) is a recognised certificate that requires the rigorous testing of product samples to determine whether the product meets specific, defined requirements. These requirements are often based on UL's published and nationally recognised Standards for Safety.
CSA approval (Canadian Standards Association) provides product testing and certification for electrical, mechanical, plumbing, gas and various other products. This approval is recognised in Canada, the U.S and various countries around the world. It includes a stringent series of flame tests on wires and cables.

Product Application Information

Hook up wire is frequently used in control panels, automotive, meters, ovens, internal wiring of computers, electronic equipment, business machines and appliances.
Alpha Wire’s FIT heat-shrink tubing and FIT wire management system can both be used with the Alpha Wire hook up wire range and are an ideal for solving many challenges in electrical and electronic wiring.

Standards

UL AWM 11028 VW-1, CSA AWM I A/B FT1, RoHS/RoHS2 Compliant, IEC 60332-2 Flame Behavior, REACH Compliant, CE Compliant

Alpha Wire EcoWire Series Hook Up Wire, Single Core, Copper - 6715 GY005

This Alpha Wire EcoWire series 18 AWG single core hook up wire with a cross-sectional area of 0.75mm² is a top choice for individuals in the automation, electronics, electrical, and mechanical industries. This wire offers superior performance and reliability for various applications, making it a go-to solution for professionals seeking quality connectivity solutions.

Features & Benefits

• Copper conductor ensures excellent conductivity and durability
• MPPE insulation provides high-quality protection for the wire
• UL11028 wire style ensures compliance with industry standards
• Green/Yellow sheath for easy identification
• CE, CSA, UL approved for safety and reliability

Applications

• Ideal for use in automation systems for reliable connectivity.
• Perfect for electronics projects due to its durability and performance.
• Well-suited for electrical wiring applications in both commercial and residential settings.
• Used in mechanical systems for efficient power transmission.
• Excellent for industrial machinery requiring high-quality wiring solutions.

Can it be used in automotive applications?

Yes, the Alpha wire Ecowire series 18 AWG Single Core Hook Up wire is suitable for use in automotive applications due to its high-quality materials and construction.

Will it provide reliable connectivity in outdoor settings?

Yes, this hook up wire is designed to withstand outdoor conditions, ensuring reliable connectivity even in challenging environments.

Is it compatible with standard electrical connectors?

Yes, the 6715 GY005 wire is compatible with standard electrical connectors, making installation quick and easy for professionals in the field.

Can this wire be used for DIY electronics projects?

Yes, this wire is perfect for DIY electronics projects, providing a reliable and efficient solution for various applications.
