1769-OW16, Allen Bradley 1769 Series PLC I/O Module for Use with MicroLogix 1500 Series, Digital, Relay, Модуль

Digital Output Expansion Modules

Choice of module types
LED indications of output status
Opto-isolation between outputs and bus and logic circuitry
Transistor output modules are source configured
Terminal identification inside cover

Allen Bradley Digital Expansion Module

The Allen Bradley MicroLogix 1500 series digital expansion module has 16 channels relay outputs. Each I/O module includes a built-in removable terminal block with finger-safe cover for connections to I/O sensors and actuators. This module is used where an application requires more I/O than the built-in I/O provided by the controller. It is compatible with MicroLogix 1500 controllers.

Features and Benefits

Ambient operating temperature ranges between 0°C and 60°C
16 normally open configuration outputs
Outputs are single ended
Supports AC/DC outputs
Operating voltage ranges between 5VAC and 265VAC or between 5VDC and 125VDC

Applications

Industrial automation
Robotics
Automobile industry

Certifications

CE compliant
C-UL certified
IEC 60068-2-6
IEC 60068-2-27
C-Tick compliant
