M245A, Gossen Metrawatt METRACAL MC Multi Function Calibrator, 24mA, 300V, Многофункциональный калибратор

Gossen Metrawatt Multi-Function Calibrator

The Gossen Metrawatt multi-function calibrator is robust, simple to handle and of the highest functionality, precision and PC system ability. It is a universal calibrator, simulator and multimeter that measures parameters in different forms like mA, mV, V/°C (Pt100/1000, Ni100/1000, thermocouples like J, L, T, U, K, E, S, R, B, N) and resistance in the range of 30ohms and 2000ohms. It rationalizes measuring, calibrating and revision work in the chemical process, laboratory and development fields, in the production area of electronic measuring transducers and at comparison and calibration of metrological components.

Supplied with
KS29 cable set, abbreviated instructions, CD ROM with operating instructions, GH-XTRA rubber holster, DKD calibration certificate.

Note
Warranty is 3-years material and workmanship, 1 year for calibration

Features and Benefits

Dual mode I/V simultaneous calibration and measurement (U / I)
Measuring and encoding in absolute terms and as percentage (scaled)
Memory for measurement results in 16MBit
Frequency and pulse running generators ranging between 1Hz and 2kHz
Ramp and staircase functions
METRAwin 90-2 interface and calibration software
Transmitter simulator (sinking configuration ranging between 0mA and 24 mA)
Rugged, EMC compliant design
Precision multimeter (V, A, Ω, F, Hz, °C / F)
30,000 (60,000) digits and triple display
TRMS AC measurement to 1kHz

Applications

Process control automation
Manufacturing
Instrumentation

Certifications

IP65 rated
ANSI/ESD S20.20:2014
BS EN 61340-5-1:2007

METRAHIT, MULTICAL Multimeter, Calibrator Operating Instructions

Datasheet
