813-SS-010-30-003191, Preci-Dip Straight Surface Mount Spring Loaded Connector, 10 Contact(s), 2.54mm Pitch, 2 Row(s), Shrouded

2.54 mm DIL Spring-Loaded Contacts, Surface Mount Pad

These Preci-dip DIL 813-S1 Series low resistance modular connectors have spring-loaded contacts (SLC) with surface mount pads.

The Height dimension gives the initial height of the spring-loaded contacts
The plastic body height is 4 mm
The plunger stroke length is 1.4 mm

Note

For counterpart SMT DIL Pad Connectors see stock number 702-0420 typical

Standards

UL 94V-0

Preci-dip Spring-Loaded Connectors

A perfect alternative to conventional connection solutions. The electrical multipoint connection between the mobile piston and the clip guarantees low, stable electrical resistance values without micro-discontinuities, even when the piston is moving or vibrating, thus assuring maximum reliability.

spring-loaded-connectors Catalogue
