1000-761, Megger DET14C Earth Tester 1.5kΩ CAT IV 600 V, Измеритель сопротивления заземления

7059422
Номер производителя: 1000-761Производитель: Megger
Цена за шт.
442500.00 руб. (С НДС) *

Срок поставки: 4-6 недель

+

* УТОЧНЯЙТЕ ВОЗМОЖНОСТЬ, ЦЕНУ И СРОК ПОСТАВКИ, В СВЯЗИ С ОГРАНИЧЕНИЕМ ЭКСПОРТА ТОВАРОВ ИЗ СТРАН ЕС И ВЕЛИКОБРИТАНИИ

Megger Earth & Ground Resistance Tester

The Megger earth and ground resistance tester measure a 1.5kΩ absolute maximum resistance and having the CAT IV 600V safety category. It is calibrated by UKAS. This 4-pole earth tester is used to measure soil resistivity and resistance of earth rods and associated installations. It is supplied in a hard carry case together with auxiliary stakes and cables. An ICLAMP selective clamp is available separately and when used with the DET4TC allows the testing of an earth rod without the need to disconnect from the system. A VCLAMP is also available separately, which when used in conjunction with ICLAMP allows stakeless measurements to be made in situations where driving auxiliary stakes is not practical. It has a rechargeable battery-powered 4-terminal tester with selectable test frequencies, greater measurement sensitivity and attached rod technique and stakeless measurement capability.

Features and Benefits

256 test results storage and recall
37mm dia conductor and 50mm earth strap capacity
4 digit plus 6 digit backlit LCD display
Accuracy guaranteed for 50Hz and 60Hz.
Auto ranging and hold function
Extended battery life
Ground resistance range between 0.050Ω and 1500Ω
High and low resistance alarms
Low maintenance flat jaw interface
Maximum current is 100Arms continuous and 200Arms for 60s max at 50Hz and 60Hz
Measurement over the ranges between 16Hz and 400Hz.
Oval clamp for easy access to earth cables and earth straps
Real time date and timestamping of results
True RMS ground leakage current ranges between 0.2 mA and 35A
True RMS readings up to a crest factor of 5.0 (peak current 40A)

Applications

Buildings, pylons and RF transmitter sites
Lightening protection systems

Certifications

EN 61010-2-032
IEC 61557-13 Class 1
IEC 61557-5

Техническая спецификация
pdfDET14C and DET24C Digital Earth Clamps Data Sheet
Абсолютное максимальное измерение температуры:
1.5кОм
Вес:
985гр
Включает в себя:
Аккумулятор, Проверка калибровки, Ремень для переноски, Футляр, Руководство пользователя
Высота:
49мм
Длина:
248мм
Источник питания:
Батарея
Категория безопасности:
CAT IV 600 В
Модель р:
DET14C
Наилучшая точность:
1.5 %
Рабочая температура - максимальная:
+50°C
Рабочая температура - минимальная:
-20°C
Срок службы батареи:
24 ч
Тип батареи:
AA
Тип дисплея:
LCD
Тип измерения:
Earth Resistance, Leakage Current
Ширина:
114мм
