ATS22C11Q, Schneider Electric Soft Starter, Soft Start, 55 kW, 440 V ac, 3 Phase, IP20, Устройство плавного пуска

Schneider Electric 3-Phase Soft Starter, 55kW Power Rating, 440V AC Voltage Rating - ATS22 Series - ATS22C11Q

Safely ramp up your heavy-duty industrial motors with this soft starter from Schneider Electric. By limiting the startup current, it ensures your motor starts gradually without being overwhelmed or damaged by sudden surges. The device comes pre-assembled with a heat sink for effective cooling to keep it performing efficiently. To prevent users making contact with live parts, this soft starter has terminals that are located out of the reach of your fingers. A power rating of 55kW makes it a practical choice for high-power applications like hydroelectric plants.

Features & Benefits

• Modbus communication protocol for easy data exchange with other connected devices
• Sound output of 56dB is within safe levels for use in industrial environments
• Low power dissipation of 73W for energy efficiency
• Internal bypass function means it runs continuously after starting for reduced heat emission

Applications

• Agricultural equipment
• Heavy-duty vehicles
• High-pressure air compressors

How do I mount this soft starter?

This soft starter is designed for mounting in a wall box or enclosure. Simply use its integrated mounting plate to secure it to the enclosure with screws. To prevent damage, it's important not to mount this device close to heat sources.

Altistart ATS 22 Data Sheet

7106427_Catalogue_en

7106427_Instruction Sheet_en

7106427_User Manual_en

Product Environmental Profile
