92-NBA4, 3M Resin Filled Cable Joint Kit, Straight Joint Type , 4 x 25 → 50mm²

Scotchcast™ Resin Kits

3M™ Scotchcast™ resin joint kits are designed to be used for 1-core up to 5-core non shielded, polymeric, low voltage energy cables. The application of these cable jointing kits incorporates electrical insulation and mechanical protection of joints with compression or mechanical connectors. They can be used for indoor and outdoor, underground and submerged applications.

Features and Benefits

• One part transparent Mould Body with Snap Fit closing system
• Quick and simple installation
• Top seal & fixing clips that reduce the chance of leakage
• Fully integrated resin delivery – safer, cleaner installation
• Provides time and cost savings through extra-fast setup
• Hydrophobic polyurethane resin
• Fast and clean installation thanks to the integrated spout
• Full transparent body shell to secure correct cable setting during installation
• Guarantees the highest grade of electrical insulation for professional application
• RoHS and REACH compliant

Why choose 3M?

3M is a trusted name in connector and wiring solutions, providing high quality cables, connectors and accessories. From industrial computing to domestic applications, 3M provides the reliable and versatile product range you need.

Supplied with

Transparent mould body with closure cap, Scotchcast™ 40 resin bag with CMP, Pre-cut sealing elements, Snap in 5-core spacer, abrasive sponge, detailed instructions

3M Cable Joint Kit, For 1-Core to 5-Core Wires, With Mixing and Pouring System - Scotchcast Series - 92-NBA4

Add this 3M cable joint kit to your toolbox to protect underground wires from corrosion and wear. It's handy to have when you're splicing or repairing low-voltage energy conductors as you can securely seal them once your job is done. The product comes in a two-chamber bag which makes mixing and pouring a doddle. For safety, this bag also minimises the chance of resin getting onto your skin.

Features & Benefits

• Includes an abrasive sponge to roughen cable jackets and achieve a durable seal
• Snap-fit closing system offers fast and easy handling
• Five-core spacer for accurate and convenient distancing between conductors

Applications

• Power utilities
• Civil engineering
• Oil and gas industries
• Water-management systems

Can I use this cable joint kit to insulate outdoor cables?

Yes, this versatile sealant is suitable for indoor and outdoor use and it's also a practical choice for submerged wiring.

Scotchcast Resin Kits 92-NB A0 up to 92-NB A7 Inline Joint Kit Series with Resin 40 Data Sheet

SCOTCHCAST Kit 92 (EN - SDS)

Scotchcast Resin Kits Datasheet
