CL240D10C, Sensata / Crydom CL Series Solid State Relay, 10 A rms Load, Panel Mount, 280 V rms Load, 32 V dc Control, Реле

Sensata | Crydom Solid-State Relay, 10A Rated Load Current, 58.8mm Height - CL Series - CL240D10C

Looking for a long-lasting switching component? This Sensata | Crydom solid-state relay is in it for the long haul. It opens and closes a circuit without moving parts, minimising wear for long-term use. As it switches on in just half a cycle, it speeds through switching to get your equipment up and running in a flash. The device's cover has an IP20 rating, which means it's finger-safe and protected against objects larger than 12mm in size for safe handling. Look for relays like this one in packaging lines and industrial robotics applications.

Features & Benefits

• Labelled conductor terminals for ease of identification during wiring
• Mounts to a panel with screws for simple and secure installation
• Compact dimensions of 58.8 (H) x 44.5 (W) x 30.9mm (D) for installation on crowded panels
• Built-in LED indicator shows input status for ease of monitoring

Does this SSR hold up under heavy vibration?

Yes, this product comes with anti-rotation barriers on its housing, so it's sure to stay strong against vibrations to prevent accidental disconnection and downtime.

Zero Voltage Relays

Note

Temperature can affect current rating; please consult the data sheet for potential derating.

Datasheet

Declaration of Conformity 2014/35/EU

CE Declaration of Conformity (2014/35/EU, 2015/863/EU)

Brochure - Panel Mount Solid State Relays

Line Drawing - CL240D10C
