15500113, Lapp 4 Core Power Cable, 2.5 mm², 50m, Black PVC Sheath, 25 A, 1 kV, 600 V

Lapp Fixed Installation Power Cable - NYY-J

From Lapp, this NYY-J cable is a widely-used power and control cable that is often found in domestic and commercial electrical wiring. As well as being used in fixed installations, the cable is designed to be used for direct burial, and burial in concrete, providing the operating temperature is adhered to.

The cable is bare copper single core with PVC with a filling compounds over the core assembly. The PVC sheath is flame retardant and robust, allowing the cable to be used in dry, damp and wet interiors. NYY-J cable is also able very resistant to UV, and so is able to be used outdoors.

Features and Benefits

• Bare copper conductors
• PVC-based outer sheath
• Suitable for outdoor use
• Flame-retardant according IEC 60332-1-2
• Above, below, flush and recess routing
• Operating temperature during installation: -5°C to +50°C
• Operating temperature in a fixed installation: -40°C to +70°C

Applications

Able to be installed in open air and underground, NYY-J cable presents a versatile power cable that should be used in where the risk of mechanical damage is unlikely. As such it can be used in brickwork and concrete, proving the concrete is not shaken, vibrated or compressed. Lapp NYY-J able is often used in;

• Power stations
• Distributor boards
• Subscriber networks

LAPP Power Cable, 4000V AC Test Voltage, PVC Jacket - NYY-J Series - 15500113

When you're laying electrical wires for direct burial, hit the ground running with this power cable from LAPP. Built with a PVC jacket and insulation, it's strong, durable and resistant to chemicals. The space around the cores is filled with a compound to keep out water. This rugged construction and an operating temperature range of -40°C to +70°C mean you can use the cable indoors and out. It's suitable for installation at a maximum depth of 0.8m to meet industry standards.

Features & Benefits

• Bare copper wires ensure it reliably delivers in extreme conditions
• Reel of 50m to cover multiple routing jobs
• Stranded conductors and a flexible jacket give it a minimum bend radius of 12 times its outer diameter of 14mm

Applications

• Construction industry
• Electrical installations
• Building infrastructure
• Property maintenance

Is this power cable fire-safe?

Yes. As it's made with flame-retardant materials, this cable plays its part in preventing the spread of fires.
