RS PRO 1 x 10 W, 1 x 10 → 16 W, 1 x 16 W, 1 x 4 → 14 W, 1 x 5 → 11 W Electronic Compact, Электронный балласт

RS PRO 1 x 10 W, 1 x 10 to 16 W, 1 x 16 W, 1 x 4 to 14 W, 1 x 5 to 11 W Electronic Compact

Regulate the current flow to your fluorescent lamps and prevent overheating using this ballast from RS PRO. It can be integrated with any lighting equipment in earthing protection Class I and II. It protects the circuitry in case of disconnection of the lamp, lamp failure or end of life.
The unit works by first preheating the coils before an arc is established. This ensures that there's no flicker and also improves the life of your lamps. As it's an electronic ballast, you won't hear any buzzing noise.
You can mount the ballast by screwing it down to your panel through the slots provided. Plus, push-in cable connections make it easy to wire. This ballast is suitable for use with emergency lighting equipment in compliance with EN (European Norms) 60598-2-22. The component is strictly tested for quality and durability.

Features and Benefits

• Not dimmable
• A2 European Union (EU) energy efficiency rating
• Dimensions of 18 (height) x 80 (length) x 41 mm (width)
• High frequency
• Operating temperature range of -15°C to +55°C
• One lamp
• T5, T8, TC-D/E, TC-DD, TC-S/E supported lamp shape
• Supports compact fluorescent and fluorescent lamp type
• Voltage rating of 220 to 240 V
• Wattage of 1 x 10 W, 1 x 10 to 16 W, 1 x 16 W, 1 x 4 to 14 W, 1 x 5 to 11 W
