PLN-20-12RS, MEAN WELL LED Driver, 12V Output, 19.2W Output, 1.6A Output, Constant Voltage, Драйвер светодиодов

RS - 20W Waterproof (IP64) SMPSU with PFC

External switch mode IP64 rated constant current and constant voltage mode power supplies
High efficiency, long life and high reliability
Designed for indoor or outdoor installations
Suitable for LED lighting and moving sign applications
Built-in constant current limiting circuit with adjustable over current protection
100% full load burn-in test
Short circuit, over-load, over-voltage, over-temperature protection
320mm un-terminated, 2-core 18AWG input lead
320mm un-terminated, 2-core 18AWG output lead
EMC compliance to EN 55015
Power factor correction to EN 61000-3-2

Note

For Industrial Use Only, not in scope of Regulation (EC) No 125/2009.

Power derates above 50°C.
MTBF to MIL-HDBK-217F.

Standards

TUV EN 61347-1, EN 61347-2-13, UL8750

Approvals

TUV, UL recognised for Canada & US
