36638-0002, Molex, CMC Automotive Connector Plug 48 Way, Solder Termination

CMC Hybrid Connector, PCB Headers

These CMC hybrid PCB Wire-to-Board Headers are right angle mount and can hold up to three different terminal sizes; 0.63mm, 1.50mm and 2.80 mm. For mating connectors see stock numbers 723-9347 or 723-9359 or 774-8144 typically.

Molex CMC Automotive Connector Plug, 48 Contacts, 14V DC Voltage Rating - CMC Series - 36638-0002

Choose this Molex CMC connector plug to link adapters to PCBs in automotive electrical systems. The durable plug has a polyester housing that offers protection from impact and corrosion to make it suitable for parts of your vehicles that are exposed to the elements. The housing also doubles as an insulator to protect you from electric shocks. With a 6A current rating and 14V DC voltage rating, this connector plug provides reliable performance in low-power systems.

• Tin-plated brass contacts for a reliable connection
• Integrated PCB retention mechanism for a vibration-proof lock on connection ports
• Wide operating temperature range of -40°C to +100°C for use in extreme conditions

Applications

• Car USB ports
• Marine industry

How do I terminate conductors to this connector plug?

This connector plug is designed for solder termination, so you achieve a permanent link and a secure connection.

Molex CMC Hybrid Connectors

Datasheet

Datasheet

Line Drawing

Application Sheet - 36638-0002

Product Specification Sheet - 36638-0002
