RS PRO 30 kW Star Delta Starter, 400 V AC, 3 Phase, IP65

When you need to start motors at a lower voltage, pick this 30 kW three-phase star delta starter. It's a practical option for situations where a motor is used intermittently or with turned on and off frequently. A star delta starter has a timer and a thermal overload to prevent it overheating, along with three efficient contacts. Use star delta motor starters to control winding currents only.

As this starter one is supplied without an overload to protect against electrical surges, you'll need to choose a compatible overload (for example stock no. 685-1309) from the RF38 series. This should match the full-load current of your motor.

Operating at temperatures ranging from -25°C to +60°C, this device is often found in manufacturing applications. Its moulded plastic case is robust enough to provide IP65 ingress protection, making it an effective defence against dust and high-pressure water jets from all directions.

Features and Benefits

• Power rating of 30 kW
• Current rating of 32 A to 38 A
• Star delta motor starter type
• Length of 220 mm
• Width of 280 mm
• Depth of 170 mm
• IP65 ingress protection
• Three poles
• Three-phase starter
• Voltage rating of 400 V AC
• Disconnect switch not included
• Compliant with RoHS (Restriction of Hazardous Substances), IEC 60947-1 (low-voltage equipment safety), IEC 60947-4-1 (protection from short-circuits)

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.

Dimensional Drawing

Selection Guide

Wiring Diagram

RS Pro Datasheet
