RS PRO Star Delta Starter, Star Delta, 22 kW, 400 V ac, 3 Phase, IP65, Пускатель

RS PRO 22 kW Star Delta Starter, 400 V AC, 3 Phase, IP65

Start motors at a lower voltage with ease with this 22 kW three-phase star delta starter. If you're using a motor intermittently or with frequent starts and stops, this is a practical option. It conveniently includes three efficient contacts, along with a timer as well as a thermal overload to stop it from overheating. Star delta motor starters only control winding currents.

To protect your starter motor against electrical surges, you might want to fit it with an overload. You can choose a compatible overload from the RF38 series (for example stock no. 685-1309) to match the full-load current of your motor.

This starter comes in a sturdy, moulded plastic case that provides IP65 ingress protection, offering an effective seal against dust and high-pressure water jets from any direction. It can be found in a variety of manufacturing environments, with operating temperatures ranging from -25°C to +60°C.

Features and Benefits

• Power rating of 22 kW
• Current rating of 24 to 32 A
• Star delta motor starter type
• Length of 220 mm
• Width of 280 mm
• Depth of 170 mm
• IP65 ingress protection
• Three poles
• Three-phase starter
• Voltage rating of 400 V AC
• Disconnect switch not included
• Compliant with RoHS (Restriction of Hazardous Substances), IEC 60947-1 (low-voltage equipment safety), IEC 60947-4-1 (protection from short-circuits)

RS PRO

RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.

Dimensional Drawing

Selection Guide

Wiring Diagram

RS Pro Datasheet
