SSH66XE34NP, Sensata / Cynergy3 Sensata/Cynergy 3 SSH66XE Series Horizontal Stainless Steel Float Switch, Float, 1m Cable, NO/NC, 300V ac Max, 300V dc

Sensata Cynergy3 Horizontal Float Switch, 500mA, 10 Bar - SSH66 Series - SSH66XE34NP

Accurately monitor either high or low media levels in a tank with this horizontal float switch from Sensata Cynergy3. For versatility, its switch action is easily reversed by mounting the device so the float moves upward instead of in its normal downward direction. The component is externally mounted, so it's a good choice for use in situations where there's no access to the inside of the tank. A maximum operating pressure of 10 bar makes the unit suitable for use in high-pressure applications. Use a float switch like this one to monitor tank levels in vending machines and laboratories.

Features & Benefits

• Stainless steel construction resists corrosion and wear for an extended service life
• Wide operating temperature range of 0°C to +120°C for use with hot and cold media
• Supplied with a DIN plug for a simple electrical connection

How much maintenance does this float switch need?

This float switch needs very little maintenance thanks to its simple, reliable technology. It consists of a reed switch and pivoted magnet for low mechanical wear. It also doesn't need to be calibrated, making it simple to set up.

SSH66XE Series External Float Switch Datasheet

Selection Guide - RSF88YP

Information Sheet - ILSE-G0100-5
