SSH66TE34NPS, Sensata / Cynergy3 SSH66TE Series Horizontal Stainless Steel Float Switch, Float, 1m Cable, NO/NC, 24V ac Max, 24V dc

SSH66 Series Horizontal Steel Float Switches

304 grade stainless steel construction, ideally suited for use in aggressive environments
Consists of reed switch and pivoted actuator magnet
High temperature operation of up to 120°C
0.1 / 1 m XLPE cable
0.75 mn SG of liquid
User configurable N/O or N/C operation by rotating through 180°

Sensata Cynergy3 Float Switch, NO/NC Switch Output, Stainless Steel Material - SSH66TE Series - SSH66TE34NPS

Looking for a reliable way to monitor and manage liquid levels in small tanks? Choose this horizontal float switch from Sensata Cynergy3. It's simple to install thanks to the 3/4-inch NPT mounting thread. As it's designed for external mounting on the side of your tank, there's no need to access the interior. For versatility, you can configure it to operate as an NO or NC switch. Thanks to its stainless steel construction, this unit is resistant to corrosion and wear. You'll find it used in applications such as vending machines and evaporators.

Features & Benefits

• Wide operating temperature range between 0°C and +120°C for use in harsh environments
• Maximum switching voltage of 24V AC/DC for use in low-power systems
• DIN connector for ease of installation

How do I reverse the switch action?

To reverse the switch action from NO to NC, simply mount this device so that the float moves upwards instead of downwards.

Can I use this float switch in high-pressure applications?

Yes, this float switch can withstand pressures up to 10 bar, making it a good choice for use in high-pressure applications.
