RS PRO Background Suppression Photoelectric Sensor, Barrel Sensor, 1 mm → 140 mm Detection Range, Фотоэлектрический датчик

RS PRO Background Suppression Photoelectric Sensor with Barrel Sensor, 1 → 140 mm Detection Range

Detect the presence, absence or distance of objects using this photoelectric sensor from RS PRO. It uses a light beam with a polarising filter to detect shiny surfaces and a red light to align them accurately. Suitable for damp environments, the retroreflective barrel sensor is contained within a nickel-plated brass body to resist corrosion.

The sensor's accuracy is enhanced by background blanking. You can expect it to detect objects from 1 mm to 140 mm. The pack comes complete with a mounting bracket and reflector.

IP67 rated, it's watertight in up to a metre of water for a full 30 minutes. CE-certified and UL-listed you can be assured that it's safe and environmentally friendly. It meets standards E348498 and NRKH7 as a safe and effective photoelectric sensor. You can find this sensor in industrial manufacturing.

Features and Benefits

• Photoelectric sensor
• Retroreflective
• Barrel style
• 4-pin M12 connector
• Flange mounting
• LED light source
• Detection range of 1 mm to 140 mm
• Phototransistor optical technology
• Retroreflective optical technology
• Maximum DC voltage of 30 V
• Maximum current of 100 mA
• Response time of 0.5 ms
• Housing material of nickel-plated brass
• IP67 rated as water-resistant
• Minimum operating temperature of -25˚C
• Maximum operating temperature of +55˚C
• PNP output
• CE-certified and UL-listed
• Meets standards E348498 and NRKH7
• Conforms to Electrostatic Control Standards ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007
• RoHS (Restriction of Hazardous Substances) compliant
