RS PRO Panel Mount Battery Isolator Switch - 315A Maximum Current, IP65, Поворотный переключатель

RS PRO Rotary Switch, 315 A, Screw

This rotary switch from our trusted RS PRO range allows you to disconnect your battery bank from your equipment and provides an extra level of protection between you and the power supply. Designed for commercial settings, it's suitable for automotive, traction and marine applications.

This heavy-duty battery isolation switch comes in a hardwearing metal casing with a fixed T-handle operation. It's IP65 rated, which means it's protected from dust. You can panel mount this switch using the pre-drilled screw terminals, so installation is easy.

Like all of our tried and tested RS PRO range, it has been tested for reliability and durability. It has a contact current rating of 315 A (amps) and functions at temperatures ranging from -30°C to +80°C. The switch has metal contacts for effective conduction and measures 64 mm in diameter.

Features and Benefits

Rotary switch
Metal casing
Screw terminals
M10 terminals (3.5mm available length)
Red actuator
Panel mounting
Metal contacts
Angle of throw is 28°
Diameter of 64 mm
Temperature range from -30°C to +80°C
Contact current rating of 315 A
Suitable for automotive, marine and traction applications
IP65 rated for protection against dust
