RS PRO Push Button Switch, Momentary, Panel Mount, 4.95mm Cutout, SPST, 32/50/125V ac, Кнопочный переключатель

RS PRO Single Pole Single Throw (SPST) Momentary Push Button Switch, 4.95 mm (Dia.), Panel Mounting, 32/50/125 V AC

Turn your circuit on and off with this RS PRO single pole single throw (SPST) momentary push button switch. There's an LED in the centre of the black switch, so you can quickly tell when your circuit's in operation. It's easy to screw this component into place, thanks to the threaded bushing. The switch can safely be soldered at up to +350°C for a maximum of five seconds
This durable sub-miniature push button switch has a maximum operating life of one million cycles. The component is IP67 rated, so it can tolerate immersion in water for up to a quarter of an hour, as well as dust and dirt. It's commonly used with industrial machinery, computer games and electronics.

Features and Benefits

• Black actuator colour
• Dome actuator shape
• Cap actuator type
• Silver case colour
• Contact AC voltage rating of 120 V, 250 V
• Single Pole Single Throw (SPST) contact configuration
• Contact current rating of 3 A at 120 V AC
• Contact DC voltage rating of 28 V
• Silver-plated brass contact material
• No illuminated
• Panel mounting type
• Panel cut out size of 4.95 mm (diameter)
• Momentary switch operation
• Solder terminal type
• Voltage rating of 32/50/125 V AC
