RS PRO Push Button Switch, Latching, Panel Mount, 4.95mm Cutout, SPST, 32/50/125V ac, Кнопочный переключатель

RS PRO Single Pole Single Throw (SPST) Latching Push Button Switch, 4.95 mm (Dia.), Panel Mounting, 32/50/125 V AC

Need an easy way to turn a circuit on and off? Turn to this single pole single throw (SPST) latching push button switch from RS PRO. It's easy to screw this component into place thanks to the threaded bushing on the front.


The component has solder terminals, so you can permanently secure it to your circuit setup. The silver-plated brass contact material is corrosion-resistant for use in harsh environments. This type of SPST latching switch is often used in telecommunication, instrumentation and medical equipment. Engineers have stringently tested this part for quality and reliability.

Features and Benefits

• Black actuator colour


• Dome actuator shape


• Cap actuator type


• Silver case colour


• Contact AC voltage rating of 120 V, 250 V


• Single Pole Single Throw (SPST) contact configuration


• Contact current rating of 3 A at 120 V AC


• Contact DC voltage rating of 28 V


• Silver-plated brass contact material


• Not illuminated


• Panel mounting type


• Panel cut out size of 4.95 mm (diameter)


• Latching switch operation


• Solder terminal type


• Voltage rating of 32/50/125 V AC
