RS PRO Push Button Switch, Momentary, Panel Mount, 6.35mm Cutout, SPDT, 32/50/125V ac, Кнопочный переключатель

RS PRO Single Pole Double Throw (SPDT) Momentary Push Button Switch, 6.35 mm (Dia.), Panel Mounting, 32/50/125 V AC

You can easily control your electrical circuit with the RS PRO single pole double throw (SPDT) momentary push button switch. This white actuator is generally found in commercial settings such as the telecommunication, instrumentation and medical industries.
For easy installation, you simply solder the snap action push button into place or panel mount it onto a hard surface. It's fitted with high-quality silver-plated copper alloy contacts for excellent energy conductivity and no voltage drops.
This reliable push button switch has a mechanical life of up to 50,000 make-and-break cycles. It's well-suited for use as a reset button and it's often found on industrial plant equipment, production lines and even arcade games.

Features and Benefits

• White actuator colour
• Cylinder actuator shape
• Cap actuator type
• Silver case colour
• Contact AC voltage rating of 120 V, 250 V
• Single Pole Double Throw (SPDT) contact configuration
• Contact current rating of 3 A at 120 V AC
• Contact DC voltage rating of 28 V
• Silver-plated copper alloy contact material
• No illuminated
• Panel mounting type
• Panel cut out size of 6.35 mm (diameter)
• Lead-free
• RoHS (Restriction of Hazardous Substances) standards met
• Momentary switch operation
• Solder terminal type
• Voltage rating of 32/50/125 V AC
