RS PRO Toggle Switch, Panel Mount, On-On, DPDT, Solder Terminal, Тумблер

RS PRO DPDT Toggle Switch, Latching, Panel Mount

Use this handy double pole double throw (DPDT) toggle switch to energise two different circuits at once using a single source of energy. This miniature version from our trusted RS PRO range has low contact resistance and can be panel mounted.

It features a chromium-plated brass actuator and the durable stainless steel ON-ON switch comes with silver-plated contacts as well as being lead-free. With a contact current rating of 5 A, the toggle also has a contact resistance of 10 mΩ. It doesn't require continuous compression as it is latching.

Toggle switches like this one are commonly found allowing or cutting off electrical currents and can be used for any automation or electrical application. We offer a variety of toggle switch accessories, such as panel mounts, plating panels and toggle switch boots.

Features and Benefits

• DPDT latching, miniature toggle switch
• Panel-mount with solder type terminal
• Contact resistance of 10 mΩ
• Silver-plated brass contact material
• Panel cut out size of 6.35 mm
• Operating temperature range of -30°C to +85°C
• Chromium-plated brass actuator material
• Mechanical life of 40000 cycles
• Actuator length of 10.41 mm
• Contact current rating of 2A @ 250 V AC
• Lead-free
• RoHS (Restriction of Hazardous Substances) compliant
