CKRD2430-10, Sensata / Crydom CKR24 Series Solid State Relay, 30 A Load, DIN Rail Mount, 280 V rms Load, 32 V dc Control, Реле

Sensata | Crydom Solid-State Relay, 0.15 to 30A Load Current Range, 4 to 32V DC Control Voltage Range - CKR24 Series - CKRD2430-10

Switching circuits is a breeze with this Sensata | Crydom solid-state relay. Supply it with an operating voltage between 24 and 280V DC and it'll fire an optical signal at its built-in photosensitive transistor. In a flash, this nifty device turns the signal into an electrical one, which lets you control circuits with a voltage between 4 and 32V DC. This jack-of-all-trades can be found in a wide variety of industrial equipment, including automation networks, robotics and medical technology.

Features & Benefits

• Broad operating temperature range between -40°C and +80°C for use in demanding environments
• Green LED indicator allows for easy status monitoring
• Dielectric strength of 4000Vrms to handle heavy electrical loads

What's the maximum wire size I can use to connect this SSR?

This SSR accommodates wires up to 10AWG in size for broad compatibility.

What's this unit's input current rating?

The typical input current used to supply this unit is between 8 and 12mA, so it's an energy-saving choice.

Instantaneous Switching

Note

Temperature can affect current rating; please consult the data sheet for potential derating.

CKR24 Series Data Sheet

Declaration of Conformity 2014/35/EU

CE Declaration of Conformity (2014/35/EU, 2015/863/EU)
