D2490-10, Sensata / Crydom Series 1 240 VAC Series Solid State Relay, 90 A Load, Panel Mount, 280 V rms Load, 32 V dc Control, Реле

Sensata | Crydom Solid-State Relay, SPST Contact Configuration, 3 to 32V DC Control Voltage Range - Series 1 - D2490-10

Need a device to change up your electrical operations? Pick this solid-state relay from Sensata | Crydom to switch your circuits on and off. It's made with no moving parts, so it's wear-resistant and maintenance-free. The product slots neatly into your setup, thanks to its compact dimensions of 44.5 (L) x 23.3 (W) x 57.3mm (H). An aluminium baseplate means this unit has the mettle for working in demanding settings, as it's resistant to corrosion and impact. You'll find SSRs like this one used to control heating elements in ovens and other home appliances.

Features & Benefits

• Functions reliably in temperatures between -40°C and +80°C for use in challenging environments
• Green LED for status monitoring in a flash
• Turn-on time of half a cycle for quick operation
• Wide control voltage range between 3 and 32V DC for versatility
• Light weight of 74.9g to place minimal strain on your equipment

Does this unit have any fire safety features?

Yes. Its housing self-extinguishes in 10 seconds or less for safety in the event of a fire.

Approvals

UL; CSA; VDE

Instantaneous Switching

Note

Temperature can affect current rating; please consult the data sheet for potential derating.
