RCD-24-0.70/Vref, Recom LED Driver, 2 → 35V Output, 24.5W Output, 700mA Output, Constant Current Dimmable, Драйвер

Constant Current LED Driver, PCB Mount with Vref - RCD-24 Series

PCB mount, constant current LED drivers for driving high power white LEDs. These PCB mount, constant current LED drivers use analogue voltage dimming and have built-in reference output voltage to power sensors or for easy analogue dimming.

Wide input and output voltage range
High operating operating temperature range
Analogue voltage dimming
Built in reference output voltage
Short circuit and overtemperature protection
High efficiency of 96%
EMC to EN55022 Class B

Note

MTBF to MIL-HDBK-217F (25°C).

Standards

EN 60950-1

RECOM LED Driver, DC Input Voltage Type, 0 to 700mA Output Current - RCD-24 Series - RCD-24-0.70/Vref

Need a power supply for your LED system? This RECOM LED driver will brighten your day. It's designed to take input voltages between 4.5 and 36V DC and convert them into a stable output of 2 to 35V. This prevents flickering and overheating so that your bulbs will keep shining on. Digital and analogue dimming control options give you greater functionality. Thanks to its operating humidity range between 5 and 95% RH, you can even use it to shed light on areas where high levels of non-condensing water vapour are present.

• High efficiency of 96% means it's an energy-saving component
• Built-in reference output voltage for powering sensors adds versatility
• 4.5g weight to avoid putting pressure on mounting surfaces
• Mean time between failures of 605,000 hours, so it's highly reliable
• Wide operating temperature range between -40°C and +71°C for use in demanding conditions

Applications

• Outdoor lighting systems
• Hospitality venues
• Medical monitors
• Downlights

What kind of lights is this unit designed for?

For wide compatibility, this unit is designed for driving high-power white LED lights.
