TMM-3-0-20-1, Amphenol ICC TMM Series Straight Through Hole PCB Header, 20 Contact(s), 2.54mm Pitch, 2 Row(s), Shrouded

DIP Male Headers

These Amphenol DIP TMM MicroMatch 1.27 mm pitch range of male Headers are for Board to Board connections. When mated with the appropriate TMM MicroMatch female Header (see stock number 739-1136 typical) they provide a Board to Board spacing of 7.1mm. The design of these TMM MicroMatch male Headers provides improved retention by including a friction lock which is utilised when mated to the appropriate Locking female Header (see stock number 739-1259 typical, with Lock).

1.27mm IDC - Amphenol TMM Range

A range of Amphenol TMM MicroMatch 1.27 mm pitch (staggered contact spacing) Board to Board or Wire to Board connectors rated at 1.5 A, 230 Vac RMS 60 Hz, DC. These TMM MicroMatch connectors are available in even number of positions from 4 to 26. All the TMM MicroMatch contacts are fully tinned with the PCB tails also being kinked to improve header retention during soldering operations. Locking latches are available on the female TMM MicroMatch connectors and the male connectors have a polarization guide to ensure correct orientation.

TMM connector series Data Sheet

TMM Series Dip type male Drawing
