XB5DSM, Schneider Electric Harmony XB5 Counter, 5 Digit, 240 V ac, Счетчик часов

Harmony XB5 Series Mechanical Hour Meter

Harmony XB5 mechanical counters
22 mm mounting diameter
Operating temperature of -25 → 70 °C
Ingress protection rating of IP66 conforming to IEC 60529

Standards

CSA C22-2 No 14, EN 60947-1, EN 60947-5-1, EN 60947-5-4, EN 60947-5-5, IEC 60947-1, IEC 60947-5-1, IEC 60947-5-4, IEC 60947-5-5, JIS C 4520, UL 508

Approvals

BV, CSA, DNV, GL, LROS, RINA, UL

Schneider Electric Counter, Analogue Display, 0 to 9999.9 Count Range - Harmony XB5 Series - XB5DSM

Make sure your numbers always add up by installing this counter from Schneider Electric. The analogue mechanism clocks up the hours from 0 to 99999.9, so, there's no need for you to manually keep track of time. The display digits are white on a black background, making them crystal-clear to read. The unit mounts flush on your control panel, ensuring it won't get in your way. Plus, a compact width of 30mm means you don't need to find much space to install it.

Features and Benefits

• Wide operating temperature range between -25 °C and +70 °C handles harsh conditions
• Durable plastic face is resistant to wear and chemicals
• Space-efficient body fits on panels with a thickness between 1 and 6mm

Applications

• Process control
• Industrial automation
• Medical devices
• Transport industry

Is this counter resistant to water?

BV
CSA approved
DNV
GL
LROS
RINA
UL approved
IP66 conforming to IEC 60529
NEMA 4X

The analogue counter is thoroughly tested for resistance to close-range washers with a pressure of 7,000,000Pa at +55°C. This counter's IP66 rating means it's not only resistant to powerful jets of water but it's dust-tight too, making it ideal for use in manufacturing areas that need to be squeaky clean.

5 Digit Mechanical Hour Counter 240 Vac
