EL1200USBIEC, Eaton 161 → 284V Input Stand Alone Uninterruptible Power Supply, 1200VA (750W), Ellipse ECO, ИБП

Eaton Ellipse ECO UPS Uninterruptible Power Supplies

The Eaton Ellipse ECO is a slim-line, high-performance surge-protection device that provides an energy-efficient power protection solution for home and business computers. The Eaton Ellipse ECO UPS power supply can make energy savings of up to 25% compared to previous-generation UPS systems, thanks to a high-efficiency electrical design and EcoControl functions (USB models).

Features and Benefits

• Once the master device is switched off, the Eaton Ellipse ECO will automatically disable peripherals.
• The Ellipse ECO UPS systems provide effective surge protection whilst also providing a power supply backup with a battery to keep your data centres operational during a power failure.
Protects data connections including Ethernet, internet and telephone lines.
• Compact and easy to install design suitable for any office environment and can be rack mount or wall mount with the appropriate accessory kit.
• Compatibility with different computer models and provides professional UPS compact protection for PC and Mac.
• An automatic battery self-test informs users when a replacement is required via an LED and an audible alarm, and the device has an easy to replace battery to maximise durability.
• Unlimited warranty for connected computer equipment.
• USB models are supplied with CD and USB cable and are compatible with all major operating systems.
Available in 500VA to 1600VA power ratings.
• Push button circuit breaker enables easy recovery from an overload or short circuit.

What is an Uninterruptible Power Supply used for?

An uninterruptible power supply (UPS) is designed to give your computers, servers, server rooms and data centres power in the case of any unexpected energy cut off or in similar applications. These power supply devices contain a battery that guarantees power to your computer system for a certain period of time. These enable the user time to save the current task and shutdown software. Uninterruptable power supplies ensure mission-critical data loss can be prevented.

Standards

Safety / EMC: IEC 62040-1, IEC60950-1 , IEC62040-2, CB Report, CE Mark
Surge Protection IEC61643 - 1

Eaton Uninterruptible Power Supply, 230 V Output, 750W - Eaton Ellipse ECO Series - EL1200USBIEC

The Eaton Ellipse ECO uninterruptible power supply (UPS) provides effective surge protection and a backup power supply to keep your equipment operational during power failures. Its slim-line design saves space and is designed for stand-alone installation or rack-mounting. This UPS automatically disables peripherals once the master device has been switched off to protect all your devices. It's energy-efficient and can reduce consumption by up to 25% compared to previous-generation models, thanks to its EcoControl functions and high-efficiency electrical design.

• Push-button circuit breaker enables easy recovery after short-circuiting or overload
• Automatic battery self-test informs users when it needs replacing via both LED (light-emitting diode) and audible alarm, with an easily-replaceable battery for reliability
• Meets international safety standard IEC61643-1 for surge protection products

What's the difference between an offline and an online UPS?

An offline UPS supplies the AC mains power directly to the load under normal conditions and switches to the battery backup in the event of an outage. This means that there is a brief disruption of about 5 ms (milliseconds) to the power supply. An online UPS supplies the AC electricity through a rectifier and inverter at all times, so there's no interruption in power.

Contains SVHC - Lead - CAS No. 7439-92-1
