9001K35, Schneider Electric 5-Axis Joystick Switch Button, IP66, Джойстик-переключатель

Schneider Electric Octagonal Joystick Switch, Spring Return, 5 Positions - Harmony 9001K Series - 9001K35

Looking for a durable joystick switch for your heavy machinery? This unit from Schneider Electric features five axes that enable it to move heavy gear in four different directions. Its slow-break switch includes a time delay, so you can control it carefully and pause it if you need to move backwards. This component features a chromium-plated metal bezel with high abrasion resistance, making it ideal for demanding applications. An IP66 (ingress protection) rating indicates that the unit's enclosure is resistant to high-pressure water jets and is protected against dust.

Features & Benefits

• 80mm operating shaft for reliable grip
• Light 0.372kg weight for easy handling and minimal strain on equipment
• -25°C to +70°C operating temperature range for versatility in industrial environments

Applications

• Printing presses
• Chemical plants
• Automotive industry
• Cranes

What's the diameter of this joystick switch?

This switch has a cutout diameter of 30mm for standard installation.

Does this joystick switch protect me from electric shocks?

As is the case with all Harmony 9001K series, this switch is integrated with an earth ground connection. This means that it's insulated against electric shocks and safe to use.

Harmony 9001K and 9001SK Catalogue

Harmony 9001K and 9001SK

9001K35 Data Sheet

Product Environmental Profile
