85310055, Werma BMW 853 Red LED Beacon, 24 V dc, Steady, Surface Mount, Wall Mount, Маячок

Werma Beacon

The Werma DC red lens, LED type beacon has a thread/membrane combination, which keeps cabling requirements to a minimum. This permanent LED beacon in attractive quadratic form has an innovative connector to create traffic light combinations. It also saves on installation time because of a Snap-On fixing bracket. You can simply drill two holes, attach the fixing bracket to the wall and snap on the beacon. The cable can be fed through one of the eight self-sealing membranes without the need for any tools. Once the cable is connected to the terminals, the lens can be clipped onto the base and secured using the four captive quick release screws.

Features and Benefits

The supply voltage is 24VDC
Wall, base and ceiling mount
Life duration of up to 50,000 hours
Easy assembly due to quick release screws
Eight self-sealing membranes for cable entry without tools
Eight integrated M20 threads, no nuts required
Conforms to the low voltage directive and EMC directive
Operating temperature is between -25°C and 50°C

Certifications

IP65 rated
CE certified
UL listed

853 Led permanent beacon Data Sheet

853 Series instructions

Machine Guarding and Safety Range Overview
