2CDS252001R0014 S202-C1, ABB System Pro M Compact S200 MCB, 2P, 1A Curve C, 400V AC, 125V DC, 6 kA Breaking Capacity

ABB MCB, DIN Rail Mounting, -25°C to +55°C Operating Temperature Range - S200 Series - S202-C1

Swiftly puts the brakes on faulty currents in your system with this MCB from ABB. It breaks an attached circuit when it detects a short-circuit or current overload to protect downstream machines from electrical damage. The unit's type-C tripping characteristic means it trips at between 5 and 10 times its 1A current rating, making it suitable for electrical systems prone to high inductive loads. Mounting this device takes just a jiffy as you clip it directly to a DIN rail.

Features & Benefits

• Breaking capacity of 6kA for safe use with heavy-duty equipment
• Integrated contact position indicator for at-a-glance status monitoring
• Built-in toggle switch for speedy resetting with a flick of the wrist
• Safe performance in harsh settings, thanks to an operating temperature range of -25°C to +55°C
• Mountable in any position to meet the needs of your setup

Applications

• Mining equipment
• Oil and gas industry
• Security systems
• Audio devices

How durable is this MCB?

With a mechanical endurance of 20,000 cycles, this MCB is tough enough to handle long-term use.

What type of terminals does it have?

The MCB has failsafe bi-directional cylinder-lift screw terminals that achieve a stable electrical connection, even under vibration.

ABB System Pro M Single & Double Pole MCB's

Note

The Classic & System pro M product cannot be intermixed and do not share common accessories. System pro M products can only be fitted to new style Protecta distribution boards,see typically stock no. 539-1553.
