2CDS272001R0021 S202M-D2, ABB System Pro M Compact S200M MCB, 2P, 2A Curve D, 400V AC, 125V DC, 10 kA Breaking Capacity

ABB MCB, 2.8Nm Tightening Torque, 3.3W Power Loss - S200M Series - 2CDS272001R0021

Keep electrical hazards at bay with this MCB from ABB. It does double duty, thanks to a delayed thermal tripping mechanism for overload protection and an electromechanical tripping mechanism for short-circuit protection. Type-D characteristics mean it trips when the supply current is 10 to 20 times its 2A rating, so it can handle very high inrush currents, such as you get from large motors. This device accommodates rigid or stranded conductors and can be easily attached to a busbar, so you've got installation options.

Features & Benefits

• Position indicator gives a clear view of your machine's status for quick troubleshooting
• Can be mounted in any position for easy set-up
• Safe to use in challenging settings, thanks to an operating temperature range between -25°C and +55°C
• Screw terminal type for convenient installation with a Pozidriv 2 screwdriver
• Low power loss of 3.3W means it's energy-efficient

Applications

• Industrial control panels
• Automotive workshops
• Signalling systems

How long will this device last?

The MCB has a mechanical lifespan of 20,000 cycles, so it's dependable over long periods.

What's the breaking capacity of this unit?

It has a breaking capacity of 10kA, so it safely interrupts a substantial fault current without sustaining damage.

ABB System Pro M Single & Double Pole MCB's

Note

The Classic & System pro M product cannot be intermixed and do not share common accessories. System pro M products can only be fitted to new style Protecta distribution boards,see typically stock no. 539-1553.
