121583-0018, ITT Cannon, APD 7 Pole Din Plug, DIN 72585, 48 V dc IP67, IP69K, Male, Cable Mount, Разъем

ITT Cannon Connectors APD Series High Power Connectors 7 Way

ITT Cannon Connectors APD Series High Power Connectors 7 way are a derivative of the 4 way APD series connectors, providing a higher concentration of pins using a 1.6mm connector system, typical applications include brake and traction control, sensors and lighting systems on trucks and trailers amongst others.

Operating voltage 48VDC
Contact resistance 5mΩ max
Voltage proof 1000 VAC (60 secs)
Insulation resistance 10MΩ min

Note

For socket contacts:273-5354 for pin contacts: 273-5348 For hand crimp tool see: 752-5723, Wire seals 752-5767, 752-5761, 752-5764, 752-5770 and for flange gasket see 752-5562

Standards

DIN EN 60529, ISO 15170-2 sec.6.2,6.3,6.4,6.6

ITT Cannon APD Series ISO 15170 Connectors

The ITT Cannon APD series of connectors are a versatile range of full plastic direct, in-line and bulkhead circular connectors, specifically designed for the transportation, off-road and special vehicle markets. These circular connectors have a strong resistance to engine transmission and brake fluids and the associated environments. The APD series is also an ideal connector for other applications including military or industrial that require harsh environment solutions while insisting on a product that is both small in size and lightweight.The APD series of connectors cover a wide range of 1 and 2-way power solutions up to 51-way interface connectors.
