20020038-H031B01LF, Amphenol Communications Solutions 5.08mm Pitch 3 Way Pluggable Terminal Block, Plug

5.08 mm pitch Pluggable Spring Clamp Terminal Blocks

The 5.08 mm Pluggable Spring Clamp Terminal Blocks have downside contacts that are offset to one side of the body, which brings them into line with the edge of the PCB when mated with Right Angled headers.

Note

For mating Straight and 90° FCI Headers see stock numbers 707-5420 and 707-5452 typical respectively.

5.08mm Pitch - FCI Pluggable Spring Clamp Terminal Blocks

The FCI range of two-part Pluggable Spring Clamp Terminal Blocks combine a high performance contact with a quick and easy installation where the stripped wires are held in place by Stainless Steel springs. The design of these Pluggable Spring Clamp Terminal Blocks incorporates a latching feature which also prevents mismatching. The dimensions of these Pluggable Spring Clamp Terminal Blocks make them End-to-End stackable. The body material of these Pluggable Spring Clamp Terminal Blocks has a UL94V-0 flammability rating.

Terminal Block Pluggable Spring Clamp 2000038 Series Customer Drawing

Pluggable Terminal Block - Design Change
