TMR 6-4810, TRACOPOWER TMR 6 DC-DC Converter, 3.3V dc/ 1.3A Output, 36 → 75 V dc Input, 6W, Through Hole, +70°C Max Temp, Преобразователь

Traco Power DC-DC Converter, ±1% Load Regulation, 1.5kV DC Isolation Voltage - TMR 6 Series - TMR 6-4810

When you need to downsize the footprint of your components, this DC-DC converter from Traco Power steps up to the mark. It comes in a compact SIP-8 package, which means it only takes up 2cm² of board space. Housed in a light and durable plastic case, it weighs in at a barely-there 4.8g. This makes the converter a no-brainer for space-saving and portable applications such as robotics and peripheral equipment. A hefty output of 3.3V DC allows the unit to power standard chips and drives in computers and electronic devices.

Features & Benefits

• Remote on/off feature gives you easy control and helps save power
• Functional isolation keeps the input and output separated to prevent electrical damage
• Continuous short-circuit protection safeguards against faults
• Performs reliably at temperatures between -40°C and +78°C to handle the challenges of plant environments

Applications

• Communications systems
• Industrial networks
• Factory automation
• Process control

What's the benefit of the converter's 36 to 75V DC input?

The wide input between 36 and 75V DC enables this DC-DC converter to take power from both battery systems and industrial circuits.

TMR 6-4810 Datasheet

Industrial Power Solutions Catalogue

Selection Guide
