DC60D100C, Sensata / Crydom Solid State Relay, 100 A Load, Surface Mount, 48 V dc Load, 32 V dc Control, Реле

Sensata | Crydom Solid-State Relay, 100A Rated Load Current, 1 to 60V DC Operating Voltage Range - Power Plus DC Series - DC60D100C

Make circuit control a walk in the park with this solid-state relay from Sensata | Crydom. Thanks to its rated load current of 100A, it can handle the demands of high-power applications. This hardy component doesn't break a sweat in harsh industrial environments thanks to its broad operating temperature range of -40°C to +100°C. As it has a maximum on-state input current of just 14mA, you can rest assured this SSR doesn't gobble up too much energy. Relays like this one are commonly used in applications such as robotics, I/O subsystems and medical technology.

• Cover has an IP20 rating, indicating it's finger-safe and protected from objects larger than 12mm in size
• Green LED indicator allows for easy status monitoring
• Light weight of 72g to place minimal strain on your equipment
• Housing is self-extinguishing for safety in the event of a fire

How reliable is this product?

This unit has an MTBF of more than 21 million hours at +40°C, so it's built to last.

DC Switching

Datasheet

Declaration of Conformity 2014/35/EU
