ZDM-01, JKL Components LED Dimmer

ZDM-01 PWM LED Dimmer

The ZDM-01 PWM LED dimmer, from JKL Components, can be connected between an LED driver and LED lighting modules to provide dimming control. With a maximum load of 8 Amps, the ZDM-01 LED dimmer can be used with constant voltage 12 V to 24 V LED devices. It also offers continuous single channel dimming from 100% full brightness to 20% without flickering. A small footprint makes the ZDM-01 LED dimmer deal for use in display cases and in architectural and cove lighting applications.

Supply voltage: 12 V to 24 V
Maximum output current: 8A
Operating temperature range: -20 to +60°C

Datasheet

ROHS and CE COMPLIANCE
