SS-5-400MA-BK, Eaton Bussmann Series 400mA Radial T Non-Resettable Wire Ended Fuse, 250V ac, Предохранитель

Cooper Bussmann SS-5 Series

Cooper Bussmann SS-5 series time-delay subminiature fuses are an ideal PCB fuse solution and can be used within a wide variety of applications.

Time-delay, low breaking capacity
Small rectangular-leaded design minimizes PCB space

CooperBussmann Non-Resettable Wire Ended Fuse

The CooperBussmann radial T non-resettable wire ended SS-5 series time delay subminiature fuse has low breaking capacity. Its small rectangular-leaded design minimizes board space and eliminates the need for additional mounting components.

Features and Benefits

• Breaking capacity is 35A at 250VAC
• Current rating is 400mA
• High inrush withstand capability
• Internationally accepted
• Operating temperature ranges between -40°C and 125°C
• Radial lead orientation
• Soldering heat resistance of 260°C, 10sec max
• Thermoplastic polyamide bodies
• Voltage rating is 250VAC High frequency vibration

Applications

• Electronic applications
• PCBs

Certifications

• IEC 60068-2-20
• IEC 60127-3
• UL 94V0

All fuses have Thermoplaste Polyamide bodies

SS-5 Series

Transition to Bussmann Series
