Lascar EL-GFX-1 Temperature Data Logger, USB, Логгер

Temperature Logger with Screen and Audible Alarm

The EL-GFX-1 USB data logger measures and stores over 250,000 temperature readings in one or more sessions over a -30 to +80 °C (22 to +176 °F) range and at a resolution of 0.1 °C for up to 1 year.

Users can easily set up their devices and view all their downloaded data by plugging the data logger into a PC. Using the free EasyLog software, users can then graph, print and export their recorded data to other applications for detailed analysis.

The EL-GFX-1 is super simple to use, with its high contrast dot-matrix LCD and three buttons users have access to real-time trend analysis, data summaries and the ability to start, stop and view results from the data logger at their fingertips. Users can even reset the maximum and minimum readings using the device's on-screen menu. This produces an event marker, which can be viewed later in the graphing software and in the data file after download.

Features and Benefits

-30 to +80°C (-22 to +176°F) measurement range
Stores over 250,000 readings
EasyLog software available as a free download
Logging rates between 10 seconds and 1 hour
On-screen graphing and menu options to start, stop, review and restart the logger in the field
Immediate, delayed, push-button or level-triggered start mode
User-programmable audible alarm thresholds with highly visible confidence/alarm LEDs
Environmental protection to IP67

Applications

Facilities Management
Housing and Business Premises
Outside Environmental Data

Note

The data logger is supplied complete with two lithium metal batteries. it is protected against moisture to IP67 when the battery case is securely fitted. Can be powered by USB.

Contains SVHC - 1,2-dimethoxyethane; ethylene glycol dimethyl ether (EGDME) - CAS No. 110-71-4

Quick Start Guide

Datasheet
