RS PRO 3 Core Power Cable, 4 mm², 100m, White PVC Sheath, 3183Y, 32 A, 300 V, 500 V

RS PRO 3-Core 4 mm² 3183Y H05VV-F Mains Power Cable, White PVC Sheath 100 m, 32 A 300 V, 500 V

If you need to wire appliances like fridges or washing machines, choose this RS PRO 3183Y power cable is the ideal solution. It's designed for use in applications involving low mechanical stress and humid conditions. For ease of identification, its three cores are sheathed in colour-coded polyvinyl chloride (PVC).


The copper wires are protected against damage from heat, mechanical stress and oil thanks to the PVC jacket. This makes the product long-lasting and safe to use. The PVC jacket is also fire-retardant for reduced fire risk. This cable is designed to meet the Euroclass Eca standards, so it can be used inside buildings that adhere to the basic fire safety requirements.

Features and Benefits

• Wire size of 11 AWG (American Wire Gauge)


• Copper conductor material


• Conductor resistance of 4.95 Ω/km


• Stranded conductor strand type


• Cross-sectional area of 4 mm²


• Current rating of 32 A


• H05VV-F harmonised code for flexible cables for small appliances


• Length of 100 m


• Three cores


• Maximum operating temperature of +70 °C


• Outer diameter of 11.17 mm


• White sheath colour


• Polyvinyl chloride (PVC) sheath material


• Meets Euroclass Eca fire safety standards


• 3183Y type flexible three-core low-voltage cable


• Voltage rating of 300 V, 500 V
