HDC200D120, Sensata / Crydom HDC Series Solid State Relay, 120 A Load, Panel Mount, 150 V dc Load, 32 V dc Control, Реле

Sensata | Crydom Solid-State Relay, Aluminium Baseplate Material, 7 to 150V DC Load Voltage Range - HDC Series - HDC200D120

Controlling your circuits is a breeze with this solid-state relay from Sensata | Crydom. Its broad load voltage range of 7 to 150V DC makes it a versatile piece of kit that's suitable for switching a wide variety of devices on and off. As it doesn't use any moving parts, there's no need to worry about wear and tear. You can find relays like this one used in applications such as medical equipment, multiplexers and I/O subsystems.

Features & Benefits

• Green LED indicator for easy status monitoring
• Rated load current of 120A means it's suitable for use in powerful electrical systems
• Light weight of 340.2g to place minimal strain on your setup
• Safe for use in harsh environments, thanks to its wide operating temperature range between -30°C and +80°C

How quickly does this unit switch on and off?

This SSR has a turn-on time between 12 and 92μs and a turn-off time between 195 and 405μs, so you can count on it to switch in a flash.

DC Switching

Solid State Relay HDC Series Data Sheet

Declaration of Conformity 2014/35/EU

CE Declaration of Conformity (2014/35/EU, 2015/863/EU)
