CWU2450P, Sensata / Crydom CW24 Series Solid State Relay, 50 A Load, Panel Mount, 280 V ac Load, 48 V dc, 280 V ac Control, Реле

Sensata | Crydom Solid-State Relay, 50A Rated Load Current, 24 to 280V AC Operating Voltage Range - CW24 Series - CWU2450P

Need a flexible switching solution to control your industrial equipment? Go with this solid-state relay from Sensata | Crydom. It converts electrical signals to optical ones, so it functions without moving parts for wear-free operation. The removable cover has an IP20 rating, so it's touch-safe and protected against objects larger than 12mm in size. This type of relay is a shoo-in for multiplexers, automation networks and instrumentation applications.

Features & Benefits

• Suitable for use in harsh conditions, thanks to its broad operating temperature range between -40°C and +80°C
• Light weight of 81.53g to place minimal strain on your setup
• Green LED indicator lets you monitor its operating status at a glance
• Compact size of 58.8 (L) x 30.9 (W) x 44.5mm (H) with cover included for installation in tight spaces
• Burning stops in 10 seconds or less for safety in the event of a fire

How reliable is this component?

This component has an MTBF of over 11 million hours at +40°C, so it's bound to last you for years.

Zero Voltage Relays

Note

Temperature can affect current rating; please consult the data sheet for potential derating.

Datasheet

Declaration of Conformity 2014/35/EU

CE Declaration of Conformity (2014/35/EU, 2015/863/EU)

Line Drawing - CW Series
