Keysight Technologies Truevolt 34460A Bench Digital Multimeter, True RMS, 3A ac Max, 3A dc Max, 1000V ac Max, Мультиметр

Keysight 34460A Truevolt Digital Multimeters

Truevolt DMMs are designed by the team that created the Keysight 34401A, the world best-selling digital multimeter. The measurements, reliability and familiarity of the 34401A are integrated in the design of the Truevolt 34460A and 34461A. Truevolt technology starts with an analog-to-digital converter which enables a patented metrology-grade architecture. Using this architecture, Keysight delivers a beautifully engineered balance of measurement resolution, linearity and speed at a value price.

Features and Benefits

• Bright 4.3in (109mm) high-resolution colour graphical display
• Intuitive menu-driven interface
• Press and hold a key to display built-in help
• Display operation can be customised to meet user needs
• Customised labels can be added
• Quick insight with graphical views of measurement results

Next Generation

The 34461A is the next generation replacement for the popular Keysight 34401A Digital Multimeter and offers 100% of the features with improved usability and measurement technology.

New features

The Digital Multimeter results are displayed in a way you have never seen before: Colour, graphical display with built-in bar chart, histogram, trend and statistics. See your results on a bright 4.3 inches, high-resolution display.
I/O: USB, LAN/LXI, GPIB (optional)
BenchVue Enabled: Control your 34460A from your PC to view and capture your data easily.

Truevolt Technology

The Truevolt Digital Multimeters are designed by the same team that created the 34401A. The 34460A represents everything you have known and trusted with your Keysight Digital Multimeter measurements for decades.

Digitising Data

Capturing a digital readout of log measurements or records for longer periods under PC control or upload data directly from the bench multimeter. Exporting data from a single Multimeter or multiple multimeters with time alignment, to programmes such as Microsoft Excel, Word and MATLAB.

Keysight Technologies Multimeter, 100Ω to 100MΩ Resistance Measurement Range, 3Hz to 300kHz Frequency Measurement Range - Truevolt Series - 34460A

Put the power of precision into your hands with this multimeter from Keysight Technologies. This bench-type device measures electrical values such as AC current, DC voltage and resistance, so it's a versatile piece of kit. A basic DCV accuracy of 75ppm ensures precise readings, avoiding the need for repeated measurements. A 4.3-inch LED-backlit display means you can view data on histograms and bar charts with ease. BenchVue Software provides an all-in-one solution for logging your data and controlling your multimeter from the comfort of your PC.

Features & Benefits

• Broad operating temperature range between 0°C and +55°C for use in extreme environments
• Compact dimensions of 303.2 (L) x 216.2 (W) x 103.8mm (H) to fit comfortably in tight setups
• Light weight of 3.7kg to place minimal strain on your setup

Applications

• Industrial automation
• Electronic equipment testing
• Fault diagnosis

What does True RMS mean?

True RMS is a type of multimeter measurement that provides the equivalent DC value of an AC waveform. It's particularly useful for measuring non-sinusoidal waveforms, which are common in many modern electronic devices.

Standards

ISO/IEC 17025

Supplied with
type":"Supplied with",

Power cord, calibration certificate
