RS PRO Mica Plastic Film, 304mm x 200mm x 0.2mm

Mica Plastic Film, 304 mm x 200 mm x 0.2 mm

Mica plastic film is specially designed to provide reliable electrical insulation at temperatures in excess of +500°C. These sheets of laminate plastic film are highly durable as well as being flexible. They're easy to cut or punch.

The sheets of thin film have a layered construction and are lightweight, supple and moisture-proof. They have outstanding thermal properties and high tensile strength. All of these features make them a reliable choice for use as electrical insulating film in high-temperature environments. This low-smoke, blister-free grade of film is resistant to flame, extreme heat and abrasion. Environmentally safe and non-toxic, it has an unlimited shelf life when kept dry and stored at room temperature.

These mica film sheets are sold in packs of five and are most often used in electronic and electrical applications.

Features and Benefits

• Rigid mica plastic film sheets
• Resistance to temperatures of over 500°C
• Dielectric strength of 25 kV/mm
• Density of 2.15 g/cm³
• Environmentally safe and non-toxic plastic film
• Length of 304 mm
• Width of 200 mm
• Thickness of 0.2 mm
• Certified by UL-94V-0 (E67143M) (flame resistance) and conforms to IEC 371-3-3 (use in heating equipment)

Why RS PRO?

RS PRO is the own brand of RS. The RS PRO Seal of Approval is your assurance of professional quality, a guarantee that every part is rigorously tested, inspected, and audited against demanding standards. Making RS PRO the Smart Choice for our customers.

Standards

RoHS Compliant, UL 94 V-O, IEC 371-3-3

RS PRO Datasheet
