MHDD25-F-T-B-S, MH Connectors MHDD 25 Way Through Hole D-sub Connector Socket, 2.77mm Pitch, Разъем

D-Sub PCB Straight Connectors MHDD Series

A range of D-Sub MHDD Series and MHDD-M Series Straight PCB Mount Plug and Socket connectors with stamped steel Tin plated shells with Ø3 mm holes.
The Insulator material for these MHDD Series and MHDD-M Series Straight PCB Mount Plug and Socket connectors is UL 94V-0 glass filled Polyester.
The Copper alloy, selective Gold over Nickel plated, terminals of these Straight PCB Mount Plug and Socket connectors are manufactured as follows:
MHDD Series:
787-3915 stamped and formed pin 9 way
787-3919 stamped and formed receptacle 9 way
787-3928 stamped and formed pin 15 way
787-3921 stamped and formed receptacle 15 way
787-3925 stamped and formed pin 25 way
787-3934 stamped and formed receptacle 25 way
MHDD-M Series:
787-3959 machined pin 9 way
787-3953 machined receptacle 9 way
787-3965 machined receptacle 15 way
787-3978 machined receptacle 25 way

MH - D-Sub Connectors

MHDD Series D-Sub PCB Mount Connectors - Catalogue Page
